Application
Create any airspace between the isolated slab and the structural deck by simply changing the length of the leveling bolt. Additionally, the top of the casting may be extended with an adapter to allow for any thickness of floating concrete slab. High load areas are handled either by adding extra mounts or by using higher capacity isolators. FLM mounts are laid out in accordance with submittal drawings provided by Kinetics.
Description
FLM consists of a resilient decoupler, cast housing, and leveling bolt. The housing incorporates two opposing side lugs for carrying concrete rebar. The leveling bolt is screwed into a threaded opening in order to lift or “jack-up” the concrete slab into final position i.e., floating the floor. Together with Perimeter Isolation Board (PIB), poly sheeting, and perimeter sealant, FLM becomes a complete floor isolation system.
Features
STC 69/IIC 61 with 4″ floating slab and 2″ airspace over 6″ concrete deck
Various load capacities offered in either fibreglass or rubber isolators
Easy to adapt for wide range of airspaces
Adapters available for thicker concrete slabs
Engineering assistance and submittal drawings offered
Factory installation and supervision available
