KINAIR Air Curtain units provide a controlled air barrier at entrances, service doors, shopfronts, cold rooms, and industrial openings to help reduce indoor air loss, improve comfort, and support cleaner building environments. With cross flow, centrifugal flow, recessed, EC motor, UV germicidal, heater, vertical, cold room, and industrial models available, KINAIR Air Curtains offer flexible doorway air control solutions for UAE, GCC, Middle East, and MENA projects.
Kinetics Noise Control Inc. Products
Doorway Air Control for Commercial, Residential, and Industrial Projects
KINAIR Air Curtain systems are designed to create a high-velocity air stream across an opening, helping separate indoor and outdoor environments while allowing easy movement of people, goods, and equipment. They are suitable for retail entrances, hotels, restaurants, offices, residential buildings, hospitals, commercial kitchens, warehouses, cold rooms, loading bays, and industrial facilities.
Wide Range of Air Curtain Designs
The KINAIR Air Curtain catalogue includes multiple product families to suit different architectural, MEP, and operational requirements. Available options include T1 luxury centrifugal flow air curtains, N cross flow air curtains, XD recessed centrifugal flow air curtains, H3 EC variable-frequency energy-saving air curtains, H3/H5/H7 cross flow air curtains, T3 simple and tasteful cross flow air curtains, X/X3/G3/P/A cross flow air curtains, UV germicidal air curtains, H centrifugal flow air curtains, large air volume industrial centrifugal air curtains, cold room air curtains, vertical air curtains, heater tube air curtains, and standing heater models.
Performance, Comfort, and Energy Support
KINAIR Air Curtains use optimized air duct designs, high-efficiency self-developed motors, centrifugal volutes, cross flow wheels, and stable air outlet structures to deliver smooth, even, and effective air curtain performance. Many models offer standard 2-speed operation, optional 3-speed operation, remote control, manual key control, wire control, and optional intelligent magnetic door switch control to reduce unnecessary indoor air outflow and support energy saving.
EC Motor and Variable-Frequency Options
The H3 EC Motor Air Curtain range is designed for higher energy efficiency and low-noise operation. The EC motor efficiency can reach 88%, and air curtain efficiency can reach 70%, which is stated as 35% higher than ordinary motors. The system supports double voltage and double frequency power supply, optional wire control and remote control, and stepless speed regulation through 4–20mA current, PWM pulse signal, or 0–10V voltage input. It also includes protection functions for phase deficiency, over voltage, blocking, over current, and temperature.
Specialized Options for Hygiene, Cold Rooms, Heating, and Industrial Use
For hygiene-sensitive areas, the Super UV Light Germicidal Air Curtain uses high-purity quartz UV lamps with a stated service life of 8,000–13,000 hours, ozone-free UV operation with a main spectrum of 253.7 nm, and a UV intensity decay of less than 30% during its life. The catalogue also includes cold room air curtains with metal housing, powder coating, high-pressure air duct design, and mounting heights up to 6–8 meters, as well as large air volume industrial centrifugal air curtains with 3-phase motor options and air velocity up to 36.5 m/s. Heater tube air curtain models include heating tube design, thermostat protection, remote control, manual touchpad control, two wind speeds, and two heating levels.
